MSI PRO B650-S WIFI DDR5 AM5 ATX Motherboard MSI PRO B650-S WIFI DDR5 AM5 ATX Motherboard MSI PRO B650-S WIFI DDR5 AM5 ATX Motherboard tv | product fter image MSI PRO B650-S WIFI DDR5 AM5 ATX Motherboard

Name: MSI PRO B650-S WIFI DDR5 AM5 ATX Motherboard MSI PRO B650-S WIFI DDR5 AM5 ATX Motherboard MSI PRO B650-S WIFI DDR5 AM5 ATX Motherboard tv | product fter image MSI PRO B650-S WIFI DDR5 AM5 ATX Motherboard
Price: 20000.0 BDT
Availability: InStock

(0 Reviews)

MSI PRO B650-S WIFI DDR5 AM5 ATX Motherboard The MSI PRO B650-S WIFI DDR5 AM5 ATX Motherboard is a powerhouse built to handle AMD Ryzen 9000, 8000 & 7000 Series Desktop Processors, providing compatibility with the most recent and powerful CPUs on the market. DDR5 memory compatibility, providing high-speed data transmission with dual-channel DDR5 7200+MHz (OC), is one of its cutting-edge characteristics. With a 12+2 Duet Rail Power System, two 8-pin CPU power connections, Core Boost, and Memory Boost, the motherboard has an upgraded power architecture that ensures reliable and efficient power supply for best performance. Its premium thermal solution includes 7W/mK MOSFET thermal pads and M.2 Shield Frozr, resulting in a high-performance system with efficient heat dissipation.

Quantity:

Order on WhatsApp Call for order

Store:

Frequently bought together

MSI PRO B650-S WIFI DDR5 AM5 ATX Motherboard MSI P...

৳20000

Jamuna 32" HD Basic TV J32BU7

৳18299

Power Pac 650VA Offline UPS

৳3399

৳41698

Save ৳ 3201

Specification

Basic Information
Supported CPU	Supports AMD Ryzen 9000/ 8000 & 7000 Series Desktop Processors Socket AM5
Chipset	AMD B650
Form Factor	ATX 243.84mmx304.8mm
Audio	Realtek ALC897 Codec 7.1-Channel High Definition Audio
Expansion Slots
PCI	2x PCI-E x16 slot 1x PCI-E x1 slot PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset) PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset)
Memory
Type	DDR5
Slots	4 DIMMs
Supported Memory	Memory Support DDR5 7200+(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200(OC)/ 5000(OC)/ 4800(JEDEC) MHz Max. overclocking frequency: 1DPC 1R Max speed up to 7200+ MHz 1DPC 2R Max speed up to 6000+ MHz 2DPC 1R Max speed up to 6000+ MHz 2DPC 2R Max speed up to 5400+ MHz Supports Dual-Channel mode Supports non-ECC, un-buffered memory Supports AMD EXPO
Maximum Memory	192GB
Graphics
Graphics	1x HDMI 1x DisplayPort Support HDMI 2.1, maximum resolution of 4K 60Hz Supports DP1.4, maximum resolution of 4K 60Hz
Connector & Ports
HDMI	1x HDMI
Display Port (s)	1x DisplayPort
USB (s)	4x USB 2.0 (Front) 4x USB 3.2 Gen1 Type A (Rear) 2x USB 3.2 Gen1 Type A (Front) 3x USB 3.2 Gen2 Type A (Rear) 1x USB 3.2 Gen2 Type C (Front) 1x USB 3.2 Gen2x2 Type C (Rear)
LAN Port (s)	Realtek 8125BG 2.5G LAN
Wireless Communication module	AMD Wi-Fi 6E The Wireless module is pre-installed in the M.2 (Key-E) slot Supports MU-MIMO TX/RX Supports 20MHz, 40MHz, 80MHz bandwidth in 2.4GHz/ 5GHz or 6GHz* bands Supports 802.11 a/ b/ g/ n/ ac/ ax Supports Bluetooth 5.3
Supported Storage	2x M.2 M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 22110/2280 devices M.2_2 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices 4x SATA 6G
RAID	Supports RAID 0 and RAID 1 for SATA storage devices Supports RAID 0 and RAID 1 for M.2 NVMe storage devices
Audio	Audio Connectors
Internal I/O Ports	INTERNAL IO: 1x Power Connector(ATX_PWR) 2x Power Connector(CPU_PWR) 1x CPU Fan 1x Pump Fan 4x System Fan 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Com Port (JCOM) 1x Tuning Controller connector(JDASH) 2x Addressable V2 RGB LED connector (JARGB_V2) 2x RGB LED connector(JRGB) 1x TPM pin header(Support TPM 2.0) 4x USB 2.0 ports 2x USB 3.2 Gen1 Type A ports 1x USB 3.2 Gen2 Type C ports BACK PANEL PORTS: DisplayPort 2.5G LAN USB 3.2 Gen 2 10Gbps (Type-A) USB 3.2 Gen 1 5Gbps (Type-A) Wi-Fi / Bluetooth Audio connectors Flash BIOS Button HDMI USB 3.2 Gen 2 10Gbps (Type-A) USB 3.2 Gen 2x2 20Gbps (Type-C)
TPM (Trusted Platform Module )	1x TPM pin header(Support TPM 2.0)
Others
Special Features	4x EZ Debug LED
Warranty Information
Manufacturing Warranty	3 Years

Product Details

Description

MSI PRO B650-S WIFI DDR5 AM5 ATX Motherboard

The MSI PRO B650-S WIFI DDR5 AM5 ATX Motherboard is a powerhouse built to handle AMD Ryzen 9000, 8000 & 7000 Series Desktop Processors, providing compatibility with the most recent and powerful CPUs on the market. DDR5 memory compatibility, providing high-speed data transmission with dual-channel DDR5 7200+MHz (OC), is one of its cutting-edge characteristics. With a 12+2 Duet Rail Power System, two 8-pin CPU power connections, Core Boost, and Memory Boost, the motherboard has an upgraded power architecture that ensures reliable and efficient power supply for best performance. Its premium thermal solution includes 7W/mK MOSFET thermal pads and M.2 Shield Frozr, resulting in a high-performance system with efficient heat dissipation. The motherboard's high-quality 6-layer PCB, constructed of 2oz thicker copper, improves longevity and stability, laying the groundwork for heavy workloads. The MSI PRO B650-S WIFI Motherboard has PCIe 4.0 slots, Lightning Gen 4 x4 M.2 with M.2 Shield Frozr, and USB 3.2 Gen 2x2 connections to meet the needs of current gaming and data-intensive applications. The motherboard provides an improved network solution with 2.5G LAN and Wi-Fi 6E, giving a secure, reliable, and fast network connection suited for both professional and multimedia applications. The introduction of AUDIO BOOST offers a greater gaming experience with studio-grade sound quality, boosting total immersion for players. In conclusion, the MSI PRO B650-S WIFI DDR5 AM5 ATX Motherboard is a feature-rich option that delivers a strong, dependable foundation for gamers and professionals looking for top-tier performance and functionality.

In Bangladesh, you can get original MSI PRO B650-S WIFI DDR5 AM5 ATX Motherboard From Star Tech. We have a large collection of latest MSI Motherboards to purchase for your Desktop PC. Order Online Or Visit your Nearest Star Tech Shop to get yours at lowest price. The MSI PRO B650-S WIFI Motherboard comes with 3 years warranty.
